Your Premier Taiwanese Manufacturer in Flat-Bed CNC Lathes

COMBO MACHINE
PV 20 SERIES

Product Description

- Model: PV-2040/PV-2060/PV-2080/PV-20120

- Swing over bed : 510mm

- Distance between center: 1000/1500/2000/3000

- Customized combo machine designed for cutting pipes and automobile transmission shafts
SPECIFICATIONS

COMBO MACHINE

PV 20 SPECS



Model PV-2040 PV-2060 PV-2080 PV-20120
Capacity
Swing over bed mm 510 (20.08”)
Swing over cross slide mm 330 (12.99”)
Swing over gap mm 700 (27.56”)
Length gap mm 300 (11.81”)
Center height  mm 255(10.04”)
Distance between centers mm 1000 1500 2000 3000
Bed width 350(13.78”) (3V+1 flat way)
Cross slide width 180(7.09”)

Headstock
Spindle bore / nose mm 250
Spindle speed range rpm 30-400
Spindle speed steps 1 step (variable speed)
Main motor HP 7.5 (inverter 7.5)

Carriage & Apron
Cross slide travel  mm 260 (10.24”)
Compound slide travel  mm 125 (4.92”)

Tailstock
Diameter of quill  mm Φ65 (2.56”)
Travel of quill mm 150 (5.91”)
Center M.T.#4

4 way tool shank mm 25(0.98”)

Net Weight  kg(lb) 1700 (3740) 2000(4400) 2500(5500) 3000(6600)
Packing: size W:1.4M H:2M L: 32.5M L: 3M L: 3.5M L: 4M
